Each fire fighting zone shall be equipped with a J-XK 2080 A field control panel, which does not need to be registered and can provide the following signals:

• Manual/automatic state output signal (passive contact signal)

• Output signal of linkage status (passive contact signal)

• Audible and visual alarm output signal ( Active output voltage signal)

• Output signal of air release indicator lamp ( Active output voltage signal )

•  Interlocking output signal (active 24V output signal)

• Solenoid output signal (active output voltage signal)

• Continuous discharge solenoid valve drive signal ( Active output voltage signal )

• Receive start/stop signal of start/stop button (passive contact signal)

• Receive status signal of manual automatic switch (passive contact signal)

• Receive blow/inhibit switch signal (passive contact signal)

• Receive the action signal of pressure switch or its corresponding feedback signal (passive contact signal)

Technical Specifications

• Communication bus voltage: DC18-30V

• Power drive bus voltage: DC5V (static), DC24V (action) Maximum drive current:<1A

• Power: DC 22～28V, With DC-DC power supply (optional): Input voltage: 40~56V, Output voltage: 24V±0.5V

• Input signal: Passive contact signal

• Output signal: four groups of active output signals and three groups of passive contact output signals

• Ambient temperature: -10～+50℃

• Relative humidity:<95% (40°C)

• 260mm×100mm×360mm(L*W*H）

Application

• Subway

• Power plants

• Mobile complexes
